cutting machines
for metal

laser technology

cutting-edge
technology

ACCESSIBILITY / FLEXIBILITY
Smartline Fiber

PROFILES AND TUBES CUTTING
Smartube Fiber

HIGH PRODUCTIVITY
Dynamicline Fiber

many
types of metal

Steel

Up to 25 mm

Stainless steel

Up to 40 mm

Aluminium

Up to 30 mm

Brass

Up to 15 mm

Copper

Up to 12 mm

cutting machines for metal

Increase your productivity
up to 60%

Flexibility
Smartline Fiber

Data Sheet
Maximum load 950 kg
Heads 1
Maximum simultaneous positioning speed 170 m/min
Maximum axial acceleration 19,6 m/s2 (2G)
Machine tolerance VDI/DGQ3441 ± 0.05 mm/m
Repeatibility ± 0.025 mm
Power output From 1 kW to 8 kW
Dimensions 3.000×1.500×100 mm
Fully enclosed and cabined machine Included
Smoke extraction system Included
Cooling system Included
Automatic table exchanger Included
Automatic loader and unloader Optional

Flexibility

For multiple changes of pieces

Accessibility

Easy use

Compact design

Ergonomics. Space saving.

PROFILES AND TUBES CUTTING
Smarttube Fiber

Data Sheet
Maximum load 15 kg/m
Heads 1 – 2D
Maximum simultaneous positioning speed 50 m/min
Maximum axial acceleration 2,5 m/s2
Machine tolerance VDI/DGQ3441 ± 0.05 mm/m
Repeatibility ± 0.025 mm
Power output From 1 kW to 2 kW
Dimensions 6.000 mm x ø220 mm
Supported formats Circular, square and rectangular
Tube dimmensions ø20 to ø120 mm
Maximum warehouse load 80 Kg/m (ø600 mm)
Automatic chip removal Optional
Extraction of cut pieces Optional

High productivity

Multiple loaders for profiles and tubes

Profiles and Tubes Cutting

Automated unloader table

Customization

Automatic loading/unloading. 2D/3D cutting heads

High productivity
Dynamicline Fiber

Data Sheet
Maximum load 950 kg
Heads 1
Maximum simultaneous positioning speed 280 m/min
Maximum axial acceleration 29,4 m/s2 (3G)
Machine tolerance VDI/DGQ3441 ± 0.05 mm/m
Repeatibility ± 0.025 mm
Power output From 4 kW to 15 kW
Dimensions 1.500×3.000×100 mm
Fully enclosed and cabined machine Included
Smoke extraction system Included
Cooling system Included
Automatic table exchanger Included
Automatic loader and unloader Optional

High Productivity

Max acceleration 4G

High Accuracy

Direct measurement and linear motors

Energy Saving

Very reduced electric consumption

STATE-OF-THE-ART AUTOMATED SOLUTIONS

WE CREATE SMART FACTORIES
WITH AUTONOMOUS DECISION-MAKING
