Mach Five®

OUR MOST PRECISE MACHINE

Numerical control with color graphics. Safety photocells. Internal silent pump. Hydraulic system regulated by synchronized valves. High precision optical lines.

Adjustable quick tie. Tooling, hardened and ground for quick tool adjustment. System of rear stops (fingers) with double linear guide, Led contact indicator.

Active hydraulic compensation system. Electrical panel with high quality components. Start & Stop system.
Hybrid system for energy saving. Model prepared for all types of automation.

High precision

High precision

High precision optical lines. High capacities and performances

Energy saving

Energy saving

Hybrid system for energy saving

Customization

Customization

Ready for all type of automations

Technical
Specifications

FeatureMach Five 30TMach Five 50TMach Five 70TMach Five 110TMach Five 170TMach Five 250TMach Five 320T
Pressing force (ton)30 50/5070110/110/110/110170/170/170/170/170250/250/250/50320/320/320/320
Bending length (mm)1250 1670/21002600 2600/3100/4100/5100/61002600/3100/4100/5100/61003100/4100/5100/61003100/4100/5100/6100
Distance between colums (mm)1200 1300/160021002100/2600/3600/4600/56002100/2600/3600/4600/56002600/3600/4600/56002600/3600/4600/5600
Throat depth* (mm)0300/300400400/400/400/400/500500/500/500/500/500500/500/500/500500/500/500/500
Travel of cylinder/piston150200/200300300/300/300/300/300300/300/300/300/300300/300/300/300300/300/300/300
Maximum table-beam distance (mm)340400/400500500/500/500/500/500500/500/500/500/500500/500/500500/500/500/500
Back gauge range (mm)800800/800800800/800/800/800/800800/800/800/800/800800/800/800/800800/800/800/800
Working height (mm)905950/950950950/950/950/950/1075950/950/950/950/1075965/965/985/1075965/965/965/965
Fast approach (mm/seg.)20020/200200200/200/200/180/150200/200/200/180/150200/200/160/150180/180/150/150
Maximum work rate (mm/seg.)0-10 0-10/0-100-100-10/0-1/0-10/0-10/0-100-10/0-10/0-10/0-10/0-100-10/0-10/0-10/0-100-8,5/0-8,5/0-8,5/0-8,5
Return speed (mm/seg.)200200/200200200/200/180/160/130200/200/200/160/130180/180/150/120180/180/140/120
Motor power (kW)3 5,5/5,51115/15/15/15/1518,5/18,5/18,5/18,5/18,530/30/30/3030/30/30/30
Oil capacity** (lit.)2540/4010100/100/100/100/100150/150/150/150/150200/200/200/200200/200/200/200
Approximate weight (ton.)3 3,8/4,28,58,5/10/12,3/14,6/15,910/12,1/15/18,7/2216,1/20/27/3318,5/22/28,7/35
MODELSDimensions
Mach Five 30T
Mach Five 50T
Mach Five 70T
Mach Five 110T
Mach Five 170T
Mach Five 250T
Mach Five 320T

* Saliente
** Aceite no incluido
