LASER AND WATERJET CUTTING MACHINES
ENERGY INDUSTRY

ONE CLIENT, ONE SOLUTION.

Laser and waterjet cutting machines for the energy sector.

TCI Cutting offers multiple industrial cutting solutions for the energy sector. Machines of different cutting technologies, laser or waterjet, that cover the cutting of different materials for the energy industry: composite materials, technical fibers such as carbon fiber or glass, resin, polymers and all kind metalls.TCI Cutting cutting machines cover different volumes, formats and cutting needs with modular and flexible systems and XXL cutting machines.

TCI Cutting’s waterjet cutting systems provide an industrial cutting solution for various companies in the energy sector. The 2D laser cutting machine Smartline Fiber offers high quality cut and maximum flexibility, perfect for companies with changing needs, with different automation solutions to fave this sector’s challenges. For large volumes, the BP-H modular waterjet cutting machines cut large formats with the possibility of cutting in 5 axes and in 2D, 2D1/2 and 3D.

The Speedline Fiber laser cutting machine is the XXL format cutting system for large parts and very specific needs in the energy sector. 2D cutting with 2D1/2 option.

XXL FORMAT

LASER CUTTING MACHINES
Speedline®

2D and 2D1/2

XXL FORMAT

WATERJET CUTTING MACHINE
BP-H®

2D, 2D1/2 and 3D

ACCESSIBILITY / FLEXIBILITY

LASER CUTTING MACHINES
Smartline®

2D

STATE-OF-THE-ART AUTOMATED SOLUTIONS

WE CREATE SMART FACTORIES
WITH AUTONOMOUS DECISION-MAKING

LASER AND WATERJET CUTTING MACHINES FOR ENERGY INDUSTRY

INCREASE YOUR PRODUCTIVITY
UP TO 80%

XXL FORMAT
Speedline Fiber

High power laser cutting machine, specially designed and developed for large formats and needs of the energy sector. 2D and optional 2D1/2 laser cutting technology for steel, stainless steel, aluminum, brass and copper, as well as plastics and fibers.

Speedline Fiber is a powerful machine that allows high quality cutting of medium and thick sheet metal and XXL formats. Get optimal energy efficiency in addition to maximum performance.

2D and 2D½ cutting

Bevel cutting option

XXL Format

Tailor-made format

Multihead

Choice of two laser sources

Technical Data
Maximum load 8.400 kg
Heads 1 or 2 (2D1/2 cutting option)
Maximum simultaneous positioning speed 170 m/min
Maximum axial acceleration 19,6 m/s2 (2G)
Machine tolerance VDI/DGQ3441 ±0.05 mm/m
Repeatibility ±0.025 mm
Power output From 1 kW to 20 kW
Dimensions multiple choices
Fully enclosed and cabined machine Included
Smoke extraction system Included
Cooling system Included
Automatic table exchanger Included
Automatic loader and unloader Optional
QUICK DOWNLOADS

XXL FORMAT
BP-H

Waterjet cutting machine for large formats and volumes. All kinds of materials regardless their hardness. Without damaging the characteristics of the material.

This series is characterized by its great versatility and great possibilities for growth and adaptation to the needs of the energy sector. With a maximum height adjustment in its Z axis up to 500 mm. The BP-H machine allows up to 4 heads and 4 bridges. XXL cutting capacity. Low temperature cutting system avoiding thermal alterations. Low operating costs.

BP series is characterized by its bridge-type construction which provides great robustness, adaptability and flexibility and allows cutting large surfaces. Modularity.

2D, 2D½ and 3D cutting

Solution for any cutting need

Modular

Expandable in length and scalable in resources. Clean and quiet working conditions. Customization

XXL Format

Tailor-made format.

5 X

5 axis cutting machine

Technical data
Maximum thickness of the part 200 mm
Maximum permitted load 790 kg/m2
Number of cutting heads 1 to 4
Maximum number of bridges 4
Simultaneous max positioning speed 85 m/min
Maximum cutting speed 20 m/min
Machine tolerance according to VDI / DGQ 3441 ±0.05 mm/m
Repetition accuracy ±0.025 mm
Dimensions multiple choices
QUICK DOWNLOADS
Máquina de corte láser Smartline Fiber

FLEXIBILITY
SMARTLINE FIBER

This series offers a perfect solution for companies with flexible processes that require continuous changes in production, both in parts and materials and thicknesses. Excellent laser cutting solution for short, long and flexible productive series and all type of materials. High production and excellent cutting quality for the energetic industry. Cutting of thin and medium thickness sheets of different metal materials.

Ideal cutting machine for those companies in the energy sector that need maximum flexibility and accessibility. 20% space saving in the factory, compact. Great energy efficiency due to its low electricity consumption. Available in powers from 1 kW to 15 kW.

2D Cutting

Flat cut

Accessibility

Ease of use

Flexibility

For multiple changes of pieces

Conception compacte

Ergonomie. Faible encombrement

DATA SHEET
Maximum load 950 Kg
Heads 1
Maximum simultaneous positioning speed 170 m/min
Maximum axial acceleration 19,6 m/s2 (2G)
Machine tolerance VDI/DGQ3441 ±0,05 mm/m
Repeatibility ±0,025 mm
Power output From 1 kW to 20 kW
Dimensions 3.000×1.500×100 mm
Fully enclosed and cabined machine Included
Smoke extraction system Included
Cooling system Included
Automatic table exchanger Included
Automatic loader and unloader Optional
QUICK DOWNLOADS

PRODUCTION
ENGINEERING

TCI Cutting offers an engineering service that diagnoses the optimal level of automation for your company and it guides you through the whole process of implementation in a modular way. We are your long-term technological partner.One client, one solution. Maximum quality and speed of implementation. Direct impact in ROI.

Transform your company into a Smart Factory and optimise your automation level with our Production Management Intelligent Software.

Tailor-made automated productive processes
Evaluation, diagnosis and technical report by our experts.

Automation implementation project
One client, one solution.

More productive and
autonomous machines

Full integration.

Management Intelligent Software
Production optimal management.

Smart
Factory

Smart factories. Industrial automation.Autonomous decision-making.
